Siemens electromotoric actuator SALxx.xxT10 N4502 for valve VBF21.xx

Manual control, position can be fixed. Plug in space for auxiliary switch and/or potentiometer.
SA..81.., SA..61.. are UL listed..

Operating voltage AC 230 V / AC24V DC24V
Positioning time 30 or 120 s
Torque 10,00 Nm
Angular rotation 90 °
IP54
Ambient temperature, operation -15…55 °C
Medium temperature -10...120 °C
Mounting position Upright to horizontal

Related products:
- ASK39.1 Weathershield for SAX../SAL..
- ASC10.51 Auxiliary switch
- ASK31N Mounting set for SAL.. onto VBF21..
- ASZ7.5 Potentiometer 0...1000 Ohm for SA..31../SA..81..

Available types SAL actuators:

SAX SAL Basic documentation (EN)

SAL Data sheet (EN)
